Why SimPEG?

Our essential functions as researchers are the pursuit and dissemination of knowledge through research and education. As scientists we seek to find models that reproduce the observations that we make in the world. In geophysics, we use inverse theory to mathematically create models of the earth from measured data. It is a difficult problem with many moving pieces: physics, discretization, simulation, regularization, optimization, computer science, linear algebra, geology. Exploring each of these disciplines can take a career, if you are so inclined, but as geophysicists we care about the combination: how to pull these disciplines together to answer our questions. This is the first problem we hope to help solve: to create a toolbox for the geophysicist that allows you to work at a high level and keep your geophysical question in focus. However, a toolbox is not enough. The research questions that we are interested in surround the integration of information to make better decisions.

We believe that the feedback loops in the geosciences could use some serious work. For example, collect multiple data-sets from the same field area (geology, seismic, electromagnetics, hydrogeology), process the data separately, and then reconvene with your multidisciplinary team. You may be rather surprised (or not) that the everyone has a (completely!?) different model. Dissonant at best, but often conflicting in the details. Therein lies the second problem: how do we integrate these geoscience fields? Not by force or even by default, but at least to have the option of quantitative communication and built in feedback loops. What we require is an implementation that is inherently and unequivocally modular, with all pieces available to manipulation. Black-box software, where the implementations are hidden, obfuscated, or difficult to manipulate, do not promote experimentation and investigation. We are working on a framework that exposes the details of the implementation to the geophysicist in a manner that promotes productivity and question based interrogation. This framework can be easily extended to encompass many geophysical problems and is built with the inverse problem as the fundamental goal.

The future we see is a mix of tools that span our disciplines, and a framework that allows us to integrate many different types of geophysical data so that we can communicate effectively and experiment efficiently. A toolbox combined with a framework that allows you to solve your own problems, and creates opportunities for us to work together to better image and understand the subsurface. What we are building is called SimPEG, simulation and parameter estimation in geophysics. We are building it in the open. We are testing it. Breaking it. Building it. Fixing it. Using it. If you believe, like we do, that geophysics can be more innovative and informative in the open and that these tools are necessary and invaluable in education as well as research, then you should get in touch. There is a lot of work to do!

The Big Picture

Defining a well-posed inverse problem and solving it is a complex task that requires many components that must interact. It is helpful to view this task as a workflow in which various elements are explicitly identified and integrated. The figure below outlines the inversion components that consists of inputs, implementation, and evaluation. The inputs are composed of the geophysical data, the equations which are a mathematical description of the governing physics, and prior knowledge or assumptions about the setting. The implementation consists of two broad categories: the forward simulation and the inversion. The forward simulation is the means by which we solve the governing equations given a model and the inversion components evaluate and update this model. We are considering a gradient based approach, which updates the model through an optimization routine. The output of this implementation is a model, which, prior to interpretation, must be evaluated. This requires considering, and often re-assessing, the choices and assumptions made in both the input and implementation stages.

Components

A Comprehensive Framework

There are an overwhelming amount of choices to be made as one works through the forward modeling and inversion process (see figure above). As a result, software implementations of this workflow often become complex and highly interdependent, making it difficult to interact with and to ask other scientists to pick up and change. Our approach to handling this complexity is to propose a framework, (see below), that compartmentalizes the implementation of inversions into various units. We present it in this specific modular style, as each unit contains a targeted subset of choices crucial to the inversion process.

Framework

The process of obtaining an acceptable model from an inversion generally requires the geophysicist to perform several iterations of the inversion workflow, rethinking and redesigning each piece of the framework to ensure it is appropriate in the current context. Inversions are experimental and empirical by nature and our software package is designed to facilitate this iterative process. To accomplish this, we have divided the inversion methodology into eight major components (See figure above). The discretize.base.BaseMesh class handles the discretization of the earth and also provides numerical operators. The SimPEG.survey.BaseSurvey class handles the geometry of a geophysical problem as well as sources and receivers. The SimPEG.simulation.BaseSimulation class handles the simulation of the physics for the geophysical problem of interest. The SimPEG.simulation.BaseSimulation creates geophysical fields given a source from the SimPEG.survey.BaseSurvey, interpolates these fields to the receiver locations, and converts them to the appropriate data type, for example, by selecting only the measured components of the field. Each of these operations may have associated derivatives with respect to the model and the computed field; these are included in the calculation of the sensitivity. For the inversion, a SimPEG.data_misfit.BaseDataMisfit is chosen to capture the goodness of fit of the predicted data and a SimPEG.regularization.BaseRegularization is chosen to handle the non- uniqueness. These inversion elements and an Optimization routine are combined into an inverse problem class SimPEG.inverse_problem.BaseInvProblem. SimPEG.inverse_problem.BaseInvProblem is the mathematical statement that will be numerically solved by running an Inversion. The SimPEG.inversion.BaseInversion class handles organization and dispatch of directives between all of the various pieces of the framework.

The arrows in the figure above indicate what each class takes as a primary argument. For example, both the SimPEG.simulation.BaseSimulation and SimPEG.regularization.BaseRegularization classes take a discretize.base.BaseMesh class as an argument. The diagram does not show class inheritance, as each of the base classes outlined have many subtypes that can be interchanged. The discretize.base.BaseMesh class, for example, could be a regular Cartesian mesh discretize.TensorMesh or a cylindrical coordinate mesh discretize.CylMesh, which have many properties in common. These common features, such as both meshes being created from tensor products, can be exploited through inheritance of base classes, and differences can be expressed through subtype polymorphism. Please look at the documentation here for more in-depth information.

Citing SimPEG

There is a paper about SimPEG, if you use this code, please help our scientific visibility by citing our work!
